HYPER S 700W

FSP

HYPER Series Power Supply meets the market mainstream and provides efficiency more than 85%.With the +12 single rail design, SATA array cable, optimized the airflow in case, no-hassle with case side panel.

Description
Specification

Complies with ATX 12V v2.4 & EPS 12V v2.92
Meets 85% Efficiency
Active PFC, Power Factor ≧ 99%
+12V Single Rail Design
PCI-Express 6+2 Pin Graphic Card Connectors
SATA Array Cable
All Sleeved Cables
120mm Quiet Fan
Complete Protections: OCP, OVP, SCP
Meet ErP/EuP 2013 Standard
Latest Intel Platform Ready
Multiple Safety Approvals

Model   HP700S
Rated Output Power       700W
Form Factor        ATX 12V V2.4 & EPS 12V V2.92
Input Voltage     200-240Vac
Input Current     5A
Input Frequency   50-60Hz
PFC   Active PFC (>0.9 typical)
Efficiency    Meet 85% @ Typical Load
Fan Type     120mm Sleeved Fan
Noise     < 19dBA
Dimensions (Lx W x H)    150 x 140 x 86 mm
Weight 1854g
Operation Temp.      0~40°C / 32°F~104°F
Protection      OVP/OCP/SCP
Safety Approval CE/TUV/KC/RCM/EAC
