NM700 M.2 2280 PCIe Gen 3x4 NVMe SSD

LEXAR

Capacities: 1TB 512GB 256GB

Description
Specification

High-speed PCIe Gen3x4 interface:
3500MB/s read and 2000MB/s write1 NVMe
M.2 2280 form factor
Get 6.5x the speed of a SATA-based SSD3
Ideal for power users
3D NAND
Features LDPC (Low-Density Parity Check)
Shock and vibration resistant with no
moving parts2
Five-year limited warranty

Color Black (PCB)
Capacity 256GB, 512GB, 1TB
Form Factor M.2 2280
Interface PCIe Gen3x4
Speed 256GB sequential read up to 3,500MB/s, write up to 1,200MB/s IOPS: 200/242K
512GB sequential read up to 3,500MB/s, write up to 2,000MB/s IOPS: 332/275K
1TB sequential read up to 3,500MB/s, write up to 2,000MB/s IOPS: 293/272K
Operating Temperature 0° to 70° C
Storage Temperature -40° to 85° C
Shock Resistant 1500G, duration 0.5ms, Half Sine Wave
Vibration Resistant 10~2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis(X,Y,Z)
TBW 256GB: 150TB, 512GB: 300TB, 1TB: 600TB
DWPD 256GB: 0.32, 512GB: 0.32, 1TB: 0.32
MTBF 1,500,000 Hours
Dimension (W x L x H) 80 x 22 x 2.25 mm
Weight 9g
Certification CE, FCC, VCCI, C-tick
